NetGate 4200

Netgate 4200

The Netgate® 4200, 4G DDR5 Ram, 16G storage. with pfSense Plus software is the most versatile security gateway in its class. The Netgate 4200 utilizes the blazing fast performance of 4-core Intel Atom C1110 CPU to achieve benchmark results up to three times faster in routing, firewall forwarding and IPsec VPN than the previous generation of security gateways. The Netgate 4200 delivers over 9.2 Gbps of L3 routing across four independent 2.5 GbE flexible WAN/LAN ports.

Built with performance, versatility, and low total cost of ownership in mind, systems with pfSense Plus software meet the growing needs of organizations of all sizes.

The Netgate 4200 Security Gateway Appliance can be configured as a firewall, LAN or WAN router, VPN appliance, DHCP Server, DNS Server, and IDS/IPS with optional packages to deliver a high performance, high throughput front-line security appliance at an excellent price. With preloaded pfSense software, the Netgate 6100 is a fast networking security solution unencumbered by traditional annual contracts, licensing fees, or artificial limitations. Built with performance, versatility, and low total cost of ownership in mind, this is a low power system built for long life and solid reliability in a compact footprint.

Easy to use

  • Pre-loaded with pfSense Plus software, ready to use right out of the box.
  • Small form-factor, so it fits about anywhere.
  • Easy GUI management. Manage pfSense settings through our web-based GUI.

Low total cost of ownership

  • No artificial limits or add-ons required to make your system fully functional.
  • No additional usage or feature based pricing. No preset limits on users, firewall rules, or IPsec tunnels.
  • Low power requirements to save money and be more eco-friendly.

Grows with you

  • Flexible configuration and support for VPN, load balancing, reporting and monitoring.
  • Simple package management system to add powerful functions and features.

Secure remote access

  • Connect via encrypted Virtual Private Networks (VPN) between offices, let mobile workers connect securely, or connect to the Cloud!
  • Use the built-in Amazon VPC Wizard to easily establish VPN connections with Amazon EC2 cloud instances.

Common use cases

  • SMB to Medium Sized Networks
  • Small to Medium Sized Branch Office
  • Managed Service Providers (MSP) / Managed Security Service Provider (MSSP) On-Premises Appliance
  • Home or Commercial High-Speed Gigabit Connections
  • Multiple VPN Connections

Software Features

pfSense software is a leading open source firewall and router distribution based on FreeBSD that is functionally competitive with expensive, proprietary commercial firewalls. pfSense software-based appliances can be configured as a stateful packet filtering firewall, a LAN or WAN router, VPN Appliance, DHCP Server, DNS Server, or can be configured for other applications and special purpose appliances. This next generation pfSense security appliance features include:

  • Stateful packet filtering firewall or pure router
  • Routing policy per gateway and per-rule for failover and load balancing
  • Transparent layer 2 firewall
  • Support for IPV6, NAT, BGP
  • Captive portal with MAC filtering, RADIUS support, etc
  • VPN: IPsec, OpenVPN, L2TP
  • Dynamic DNS client
  • Reporting and monitoring features with real time information

HARDWARE SPECIFICATIONS:

CPU

Intel® Atom® C1110 @ 2.1 GHz w/AVX2

CPU Cores

Quad Core

Physical Network I/O ports

4 x 2.5 Gbps "direct" (unswitched) WAN/LAN ports (RJ45)

1 x USB 3.0

Storage

16GB

Memory

4 GB DDR5

Physical Expansion Card Slots

1x m.2 (Key-B slot) with dual-SIM (LTE, Wi-Fi, or NVMe)



Console Port

1 x auto-detect console port: "Cisco pinout" RJ45 + micro-USB (micro-USB cable included with each system)

USB Ports

1x M.2 (B-key slot) USB
1x M.2 (B-key slot) x1 PCIe 3.0, USB
1x M.2 (M-key slot) x4 PCIe 4.0

LED

3 x RGB LED(s) software / bootloader controllable via Microchip MCU

Enclosure

Desktop - Aluminum, plastic, and steel enclosure.
8.66 x 7.1 x 2.3 inches
220 x 180 x 60 mm

Mounting

Optional wall mount kit

Cooling

Passive - integrated aluminum chassis and heatsink

Power

External ITE P/S AC/DC 100-240V, 50-60 Hz, 12V 5.0A (60W), threaded (locking) barrel connector.

Specifications (not final):

- AC Inlet: IEC320-C7 (2 PIN) - Power Cord: One US, UK, EU or ANZ power cord included

- US Power Cord: NEMA 1-15-P to IEC320-C7

- UK Power Cord: BS 1363 to IEC320-C7

- EU Power Cord: CEE7/16 to IEC320-C7

- ANZ Power Cord: AS 3112 (ungrounded) to IEC320-C7

Environmental

0°C (32°F) to 40°C (104°F) - ambient

Certifications CE, CB, FCC (Class B), RoHS, CCATS, UL, RCM, UKCA



The World’s Leading Open-Source Next Generation Firewall firmware, VPN, Wireguard and Router. Proven value with over 1 million installations worldwide. Deploy today on a Netgate appliance to gain autosense; autodefense, IDS, IPS as Next Generation Firewall, overall capability or Active connections are very depending on pfsense setting, log policy, addon modules and hardware spec with full susprises. or can further collaborate with the high speed Netgate TNSR Edge Router ...

Read More ...


Collect metrics / problem detection for Netgate Firewall, pfSense, OS & applications

Read More ...

NetGate 2100

  • Marvell Armada 3720 (88F3720) ARMv8-A 64-bit Cortex A53 @ 1.2GHz with NEON SIMD and FPU
  • 4 GB DDR4 RAM, 8GB eMMC Flash on board
  • One 1 Gigabit Ethernet WAN port (RJ45 / SFP Combo)
    Four 1 Gigabit Ethernet LAN ports (Marvel 88E6141 switch, uplink at 2.5 Gbps)
    LAN ports can be repurposed for additional WAN ports
  • 1x Mini PCIe slot(1)
  • USB2.0x1, 1x Micro USB port (console)
  • 1 Million active connections
  • L3 Forwarding: 1.5G Mbps
  • Firewall: 881 Mbps
  • IPsec VPN: 118 Mbps
  • Desktop 1.7" (42.2 mm) tall x 4.25" (108 mm) deep x 6.8" (172.7 mm) wide
    with integrated keyholes for optional wall mounting

Read More ...

24 hrs Support Center :
you can issue a ticket to get support... or call our office or Emergency Business WhatsApp : +852.2312 0878

connect support center ...

Virtual Data lease line by pfsense Next Generation Technology.

Enquiry please call our office or Emergency Business WhatsApp : +852.2312 0878

connect support center ...

Netgate 8200

  • Intel® Atom® C3758R with QAT, 8-core @ 2.4 GHz
  • 16GB DDR4, 128G Storage
  • 4x GbE RJ45, 2 x SPF, 2 X Combo
  • 10.0 Million active connections
  • L3 Forwarding: 18.6 Gbps
  • Firewall: 18.5 Gbps
  • IPsec VPN: 3.24 Gbps

Read More ...

Netgate 6100

  • Intel® Atom® C3558 with QAT, 4-core @ 2.2 GHz (Denverton family)
  • 8GB DDR4, 16G Storage
  • 4x GbE RJ45, 10G x SPF, 2 X 1G Combo
  • 10.0 Million active connections
  • L3 Forwarding: 18.6 Gbps
  • Firewall: 18.5 Gbps
  • IPsec VPN: 3.24 Gbps

Read More ...

Netgate 8300

  • Intel Xeon D-1733NT, 8-core @ 2.0 GHz
  • 16GB DDR4, 512G NVME Storage
  • 4 x 2.5G RJ45, 4 x 1G SPF, 4 x 10G SPF+
  • 50.0 Million active connections
  • L3 Forwarding: 36.7 Gbps
  • Firewall: 26.8 Gbps
  • IPsec VPN: 14.6 Gbps

Read More ...
